2. Properties

(1) Appearance                             Semi-transparent liquid

(2) Specific gravity                          1.01 (at 25°C)

(3) Density of solid component                3 mass %

(4) Principal solvent                          Water

(5) Recommended dilution multiples           10 – 15 times

(6) Hazardous material classification           Non hazardous material

(7) Diluting solvent                          Water (tap water, ion-exchange water)

3. Scope of application

Rubbers: SBR, NBR, EPDM, CR, U, FKM, etc.

Thermosetting resins: Epoxy, Non-saturated Polyester, Phenol resin, etc.

Thermoplastic resins: PE, PP, PVC, PS, ABS, PA, POM, PC, etc.

4. Method of use

4-1 Dilution Use the mold release agent straight or dilute with water (desirably ion-exchange water) appropriately, and agitate it until uniformly mixed.

Part of the ingredients may settle out. In that case, agitate the mold release agent well before use. If diluted, finish up the product immediately. Avoid long storage of dilute solution.

4-2 Application Before using the product for the first time, remove the old mold release agent completely.

Apply a uniform coating film using an air spray device, brush, or rag.

When spraying on a mold, desirably spray the mold release agent lightly a few times.

It is more effective to apply a few thin coating films of low concentration of the agent than to apply one thick coating film of high concentration of the agent.

Be sure to use an appropriate amount of the agent since use of an excessive amount may result in mold contamination.

4-3 Cleaning the mold Slight contamination or the mold release agent can usually be removed to a certain degree by wiping with a solvent (IPA, toluene, acetone, etc.). Alkaline cleaning agents are effective for complete removal. (Immerse in an approx. 10% aqueous solution of potassium hydroxide or sodium hydroxide to which a small amount of surface active agent has been added. The cleaning solution should be at a temperature of 60–80°C.)

5. Usable temperature range

Room temperature to 200 °C

6. Cautions on handling

(1) Be sure to read the Material Safety Data Sheet (MSDS) and precautions on the label before using

   this product.

(2) Do not use this product for other than industrial purposes.

(3) Store in a cool and dark place. Avoid long time storage at a temperature over 40°C.

  In a cold climate, take care so that this product does not get frozen. (Once frozen, the original state

  cannot be recovered even if it is unfrozen.)

(4) Use in a place which is well ventilated. Local exhaust equipment should be installed if necessary.

(5) Wear protective goggles when using this product to avoid letting the agent come into contact with

   eyes. If the agent gets into eyes, wash immediately with clean water and seek medical attention.

(6) Wear rubber gloves, protective clothing, etc. when using this product to avoid letting the agent

   come into contact with skin. If it comes into contact with skin, immediately wash with soap and water.

(7) If by any chance it is swallowed, do not let the person vomit but seek medical attention

  immediately.

(8) Wash your hands and rinse your mouth with copious amounts of water after use.

* This product has been developed for industrial purposes and we shall not guarantee the safety if

used for any other purposes. If it is going to be used for medical and/or food applications, please contact us in advance.
